nVidia Mellanox Spectrum based 100GbE 1U Open Ethernet Switch with MLNX-OS, 32 QSFP28 ports, 2 Power Supplies (AC), Stan








  • nVidia Mellanox Spectrum based 100GbE 1U Open Ethernet Switch with MLNX-OS, 32 QSFP28 ports, 2 Power Supplies (AC), Stan










Kód:
9MMSN2700CS2F
P/N:
MSN2700-CS2F
Výrobce:

Mellanox

Záruka:
12 Měsíců



ks.


PRA - Sklad Praha,
BRA - Sklad HL Bratislava,
EXT - Externí sklad: Pro termín dodání kontaktujte svého obchodníka














  •
  •


Podrobnosti o produktu





Popis produktu:

BENEFITS
–– Highest ROI - energy efficiency, cost savings and
scalable high performance
–– High-performance fabric for parallel computation
or I/O convergence
–– Quick and easy setup and management
–– Maximizes performance by removing fabric
congestions
KEY FEATURES
–– 324 EDR (100Gb/s) ports in a 16U switch
–– 64Tb/s switching capacity
–– Ultra-low latency
–– IBTA Specification 1.3 and 1.2.1 compliant
–– Quality of Service enforcement
–– N+N power supplies

MELLANOX CS7510
- 16U modular chassis
- 36 QSFP28 EDR 100Gb/s InfiniBand ports per
dual IC leaf blade
SWITCH SPECIFICATIONS
- Compliant with IBTA 1.21 and 1.3
- 9 virtual lanes: 8 data + 1 management
- 256 to 4Kbyte MTU
- 4X48K entry linear forwarding data base
MANAGEMENT PORTS
- DHCP
- Familiar Industry Standard CLI
- Management over IPv6
- Management IP
- SNMP v1,v2,v3
- Web UI
FABRIC MANAGEMENT
- On-board Subnet Manager supporting fabrics
of up to 2048 nodes
- Unified Fabric Manager™ (UFM™) Agent
CONNECTORS AND CABLING
- QSFP28 connectors
- Passive copper or active fiber cables
- Optical modules
INDICATORS
- Per port status LED Link, Activity
- System status LEDs: System, fans, power
supplies
- Port Error LED
- Unit ID LED*
PHYSICAL CHARACTERISTICS
- Dimensions: 28’’H x 17.64’’W x 30.3’’D
- Weight: Fully populated 275kg (606lb)
POWER SUPPLY
- Hot swappable with N+N redundancy
- Input range: 180-265VAC
- Frequency: 47-63Hz, single phase AC
COOLING
- Hot-swappable fan trays
- Front-to-rear air flow
- Auto-heat sensing fans
POWER CONSUMPTION
- Typical power consumption (fully populated):
• Passive cable - 4939W
• Active cable - 6543W

Ordering Part Number/Description
MCS7510 64Tb/s, 324-port EDR chassis switch, includes 12 fans and 6 power supplies, (N+N configuration) RoHS-6
MSB7510-E Switch-IB™, 36-port EDR 100Gb/s InfiniBand leaf, RoHS-6
MSB7520-E Switch-IB™, 36-port EDR 100Gb/s InfiniBand spine, RoHS-6
MMB7500 x86 dual-core management module, RoHS-6
MTDF-FAN-A Director system fan unit located on the leaf side
MTDF-FAN-B Director system fan unit located on the spine fan unit
MTDF-PS-A 2.5 KW AC Power Supply w/ P2C air flow
