ASRock Rack 1U server Intel (LGA 1700) 4xDDR5 PCIe5.0 1x16x 1xM,2 4x3,5"HS 2x2,5"Fix 2x10GB 2x1GB Lan 80+Gold 400w








  • ASRock Rack 1U server Intel (LGA 1700) 4xDDR5 PCIe5.0 1x16x 1xM,2 4x3,5"HS 2x2,5"Fix 2x10GB 2x1GB Lan 80+Gold 400w










Kód:
AG1U4LWC2622L2T
P/N:
1U4LW-C262/2L2T
Výrobce:

Asrock

Záruka:
12 Měsíců




ks.

 Koupit


PRA - Sklad Praha,
BRA - Sklad HL Bratislava,
EXT - Externí sklad: Pro termín dodání kontaktujte svého obchodníka














  •


GPSR




Kontakt:
ASRock EU B.V.
Bijsterhuizen 11-11, 6546AR, Nijmegen, the Netherlands
sales@asrock.nl
  •


Podrobnosti o produktu





Popis produktu:

 System
Form Factor 1U Rackmount
Dimensions 534.35 x 430 x 43.3 mm (21” x 16.9” x 1.7”)
Support MB EC262D4U-2L2T
 Front Panel
Buttons Power Switch, ID Switch, System reset, NMI
LEDs Power status, HDD, LANs, System Fail activity LEDs
I/O Ports 2 Type-A (USB3.2 Gen1)
 External Drive Bay / Storage
Front Side Drive Bay 4 Hot-swap 3.5" SATA drive bays
Front Side Backplane 4-port 6Gbps passive backplane
Internal Side 2 fixed 2.5" NVMe (PCIe4.0 x4) drive bay
1 M-key (PCIe4.0 x4); support 2280/2260/2242/2230 form factor [PCH]
 Power Supply
Type Single fixed PSU
Output Watts 400W @ 100-240Vac input
Efficiency 80-PLUS Gold
AC Input AC 100-240V/6-3A, 50-60Hz
 System Fan
Fan 5 PWM Easy-swap 40x28 mm fans
 Processor System
CPU Supports Intel® Xeon® 6300-series, Xeon® E-2400 series, and Pentium® Gold G7400/G7400T processors
Socket Single Socket LGA 1700
Thermal Design Power max. up to 95W (TDP)
Chipset Intel® C262
 System Memory
Supported DIMM Quantity 4 DIMM slots (2DPC)
Supported Type Supports DDR5 288-pin ECC UDIMM
Max. Capacity per DIMM 32GB
Max. DIMM Frequency 4400MT/s (2SPC - 1DIMM) / 4000MT/s (2SPC - 2DIMM 1R) / 3600MT/s (2SPC - 2DIMM 2R)
Voltage 1.1V
 PCIe Expansion Slots (SLOT7 close to CPU)
PCIe x 16 1 FHHL PCIe5.0 x16 via RB1UX16R_G5
 TPM
TPM support 1 (13-pin, SPI)
 Ethernet
Additional GbE Controller 2 RJ45 (10GbE) by Intel® X710
2 RJ45 (1GbE) by Intel® i210
 Server Management
BMC Controller ASPEED AST2600: iKVM, vMedia support
IPMI Dedicated GLAN 1 RJ45 Dedicated IPMI LAN port by Realtek RTL8211F
 Graphics
Controller ASPEED AST2600:
1 DB15 (VGA)
 Rear I/O
UID Button/LED 1 UID button w/ LED
Video Port 1 DB15 (VGA)
Serial Port 1 DB9 (COM)
USB 3.2 Gen1 Port 2 Type-A (USB3.2 Gen1)
RJ45 2 RJ45(10GbE), 2 RJ45(1GbE), 1 dedicated IPMI
 System BIOS
BIOS Type AMI 256Mb SPI Flash ROM
BIOS Features Plug and Play, ACPI 6.4 and above compliance wake up events, SMBIOS 2.8 and above, ASRock Rack Instant Flash
 Hardware Monitor
Temperature CPU, MB, Card side, VR, DDR5, PCH, M.2, X710, TR1 Temperature sensing
Fan Fan Tachometer
CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
Fan Multi-Speed Control
Voltage 3VSB, 5VSB, CPU_VCORE, VCCIN_AUX,VDD2, 1.05V_PCH, 0V82SB_PCH, 1V8SB, VCCSA, BAT, 3V, 5V, 12V
 Environment
Temperature Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C
Humidity Non operation humidity: 20% ~ 90% ( Non condensing)


Stránky o produktu:

https://www.asrockrack.com/general/productdetail.asp?Model=1U4LW-C262/2L2T#Specifications











Parametry





Základní parametry
Provedení serveru:  Standardní rackový server
Formát:  1U

Procesor
Procesor:  Intel

Pevný disk
Typ řadiče:  SAS
Rozměr disků:  2,5" a 3,5"

Paměť
Typ paměti:  DDR5
Počet paměťových slotů:  4
